BETTER STRUCTURE: No gearbox, using safer direct drive technology
SMOOTHNESS CONTROL: unit with Vector Control Algorithm, more smooth
SAFETY :Precise control of opening and closing force, rapid rebound reaction when encountering resistance, easy reverse push, safety anti-pinch
ULTRA QUIET :No transmission structure friction, the door machine runs comfortably and quietly
AUTO LEARNING: Self-learning stroke after power-on, adaptive control operation path, mobile phone debugging, low maintenance cost
EASY OPERATION :Support pre-factory debugging settings, convenient installation without threshold
|
Model |
QT- 68 Door Unit
|
|
Door Leaf Form
|
Single/Dual |
|
Door Leaf Weight
|
150kg*1/75kg*2 |
|
Applicable door materials
|
Glass doors, stainless steel edging doors, aluminum alloy doors, wooden doors, etc.
|
|
Standard Track Length
|
4.2m(cut）
|
|
Standard Belt Length
|
8.5m(cut）
|
|
Standard Adaptive Door Width
|
Single 500mm ~ 2100mm Dual 500mm ~ 1050mm
|
|
Rated Power
|
25W
|
|
Power Type
|
AC100-240V,50/60Hz
|
|
Standby Power
|
＜ 5W(No lock state)
|
|
Anti-pinch Force
|
≤ 10N(Safe and no harm)
|
|
Open/Close Speed
|
100~500mm/s(Adjustable)
|
|
Hold Time
|
0 ~ 30s(Adjustable)
|
|
Ambient Temperature
|
-30℃ ~ 50℃
|
